Roger Technology Sliding Gate Motor - Medio 600kg

Brushless Motor Technology

The Roger Technology Medio 600kg sliding gate motor delivers rapid operation that significantly reduces waiting times compared to conventional gate automation systems. Its high speed performance combines efficiency with refined elegance, enabling swift gate cycles without compromising on quality or control. Perfect for applications where quick access and smooth operation are essential priorities.

The ideal solution for all installations requiring speedy manoeuvre times, intensive use, maximum movement elegance and total safety during the movement and obstacle detection phases.

Experience the cutting-edge performance of Roger Technology's Medio 600kg sliding gate motor, engineered with advanced brushless technology that delivers exceptional power and reliability. This high-speed electromechanical operator features integrated digital control via the native encoder, and irreversible operation for enhanced security. Designed for gates up to 600kg, it combines Italian precision engineering with energy efficient sliding gate performance.

The complete package includes motor with 2 remote controls, mechanical limit switches and a built-in 2 channel radio receiver for seamless automation. Ideal for demanding residential and commercial applications requiring superior durability and minimal maintenance.

Italian made automation

• Purpose : For sliding gates up to max 600 kg.
• Safe: The encoder management allows precise and safe control of slowdown when opening and closing.
• Feature Packed : Automatic programming via the learning function of the control board
• Quick: Ease of installation and start up due to its simple functions and its height and depth adjustments.
• Strong: Features a sturdy aluminium base treated with anti-corrosive paint and a reliable Roger Brushless motor mounted in dedicated housings and bearings.
• Equipped with a release lever and an easy-to-operate lock.

• Convenient: Battery backup option available

Optional mounting bases are available for a clean and simple installation

Specifications:

• Brushless Operator Made in Italy
• Max Gate Size - up to 600kg
• Input Power - 230V AC
• Motor Power - 130W, 24V AC Three Phase brushless
• Max thrust - 500N
• Speed - 26m/min
• End Stops - magnetic
• Control Board - B70-1DC

Power Options:

• Mains - the most reliable option if it is possible to get 230v out to the gate.
• External Low Voltage Transformer - put a transformer inside the house or garage and run low-voltage AC out to the gate using a garden light cable.
• Solar - Roger Automation is very energy efficient and suits solar power. The specification of your panel(s) and batteries depends on your application and we will help you select the right solar solution.


Why Choose Roger?

• High torque to weight ratio – these low voltage motors can now be applied to applications that were once only served by larger 230v motors.
• Increased efficiency – Significantly reduced losses due to the motor construction. The omission of brushes and the fact that the motor windings are supported by the motor housing, any heat generated is cooled by conduction resulting in ultra low power consumption and a super intensive duty cycle.
• Longer lifetime - increased reliability and reduced noise – This is achieved due to the elimination of brush or commutator erosion, ionizing sparks and the overall reduction of electromagnetic interference.
• Higher speeds – Brushless motors are capable of higher speeds without the loss of torque. Brushed motors develop maximum torque when stationary, linearly decreasing as velocity increases.
• Superior control & motor positioning – Utilising the pulses from the undriven coils within the brushless motor and the technology incorporated in the controller the motor is capable of achieving precise control and positioning. One obvious advantage to this is significantly reduced stresses to the motor and gearbox resulting in the overall longevity, sustainability and reliability of the unit.
